| Function item |
Semflex-VM Series
Specification |
Remarks |
| Main power supply |
3 phase AC2000 / 400V |
|
| Control CPU |
16bitCPU A/D D/A 16MHz |
|
| LCD |
Open （%）・Abnormal display icon |
|
| Basic operation |
Site and distance change
（open, stop, and close） |
|
| Speed adjustment |
A/BGear or Inverter |
|
| Positional limit |
Position setting range：
Max 5,000 tums
0%・100%・Middle 3places |
The rotational speed of Drive sleeve is detected.
（Electronic absolute encoder）
Maximum angular resolution to 5°of Drive sleeve. |
| Torque limit |
30〜100% of max tprque
Sets it every 1% |
The amount of the movement of Worm is detected.
（No contact potentiometer）
Accuracy ± 5% |
| Backup |
1 year after power failure |
|
| Option |
Proportion comtrol
Fieldbus（PROFIBUS-DP）
Self-diagnosis function |
|
